25200018-001 SCR Screw Air Compressor Genuine Parts Oil Filter

No.25200018-001
Genuine SCR oil filter 25200018-001, rated to 50 micron. Protects bearings and rotors from metal particles and oil breakdown. 2 kg, ships in 1-2 weeks.
$98.00
  • 25200018-001 SCR Screw Air Compressor Genuine Parts Oil Filter
  • 25200018-001 SCR Screw Air Compressor Genuine Parts Oil Filter
  • 25200018-001 SCR Screw Air Compressor Genuine Parts Oil Filter
  • 25200018-001 SCR Screw Air Compressor Genuine Parts Oil Filter
  • 25200018-001 SCR Screw Air Compressor Genuine Parts Oil Filter

Description

Part No 25200018-001
Brand SCR
Origin China
Weight 2 kg
HS Code 8414909090
Fits SCR screw air compressors
Lead time 1-2 weeks

The oil filter removes metal particles and oil breakdown products from the coolant before it reaches the bearings and rotors. It is a paper element rated to 50 micron, and everything it catches is material that would otherwise circulate through the bearing surfaces at pressure.

A blocked filter does more than stop filtering. It starves the airend of coolant, which shows up first as high discharge temperature and a trip, then as shortened bearing life.

Signs it needs replacing

  • The filter differential pressure indicator sits in the red
  • Discharge temperature rises with no change in ambient or load
  • Oil pressure drops at the same load
  • Pleats are collapsed or the element is crushed on removal, a sign it bypassed

Replacement interval

First oil and filter change at 500 hours on a new machine, then every 2,000 running hours. Shorten the interval where the oil runs hot or the site is dirty.

Change the oil at the same time. A new filter on old oil simply collects the sludge the old oil is already carrying.

How to replace

  • Stop the machine, depressurise and let it cool.
  • Clean around the filter head before unscrewing the element.
  • Check the old seal and the head face for trapped debris.
  • Oil the new seal, fit by hand, then torque to spec. Over-tightening distorts the seal.
  • Run briefly, stop, and check the head for weep.

Replaced together

Change the air filter in the same stop. On SCR machines the two are usually scheduled together:

Genuine vs alternative

We supply the genuine SCR element under this part number. Filtration rating and burst strength are what separate it from a copy, and a 50 micron paper element is not where to save a few dollars.

Genuine SCR: USD 75

Ordering notes

Quote 25200018-001 with your machine model. Weight 2 kg. Lead time 1-2 weeks.
