25100130-072 SCR Screw Air Compressor Genuine Parts Air Filter

No.25100130-072
Genuine SCR air filter 25100130-072. 500 mm paper element for screw compressors, 1 kg, ships in 5-7 days.
$35.00
  • 25100130-072 SCR Screw Air Compressor Genuine Parts Air Filter
  • 25100130-072 SCR Screw Air Compressor Genuine Parts Air Filter
  • 25100130-072 SCR Screw Air Compressor Genuine Parts Air Filter
  • 25100130-072 SCR Screw Air Compressor Genuine Parts Air Filter
  • 25100130-072 SCR Screw Air Compressor Genuine Parts Air Filter

Description

Part No 25100130-072
Brand SCR
Origin China
Weight 1 kg
Dimensions 18 × 18 × 50 cm
HS Code 8414909090
Fits SCR screw air compressors
Lead time 5-7 days

What it does

A dry paper element on the intake side. It stops dust before the airend sees it; everything that gets past is abrasive and ends up between the rotors and in the bearings. At 500 mm long, this element carries more pleated area than the compact elements on small machines, which is why it holds up longer in a dusty plant.

Signs it needs replacing

  • The intake restriction indicator stays in the red after cleaning
  • Pleats are torn, or the element is saturated with oil mist from a breather
  • Dust tracks past the seal, meaning the gasket has stopped sealing rather than the paper failing
  • Restriction rises quickly again after each cleaning

Replacement interval

Clean every 1,000 running hours from the inside out with low-pressure air. Replace every 2,000-3,000 running hours in normal conditions, and shorten that where the intake draws dusty air.

Each cleaning removes a little of the paper's structure. After three or four passes the element looks serviceable but no longer filters to the same level, and the restriction gauge will not tell you that.

How to replace

  • Stop the machine and isolate the intake.
  • Clean around the housing cover before opening it.
  • Withdraw the element straight out. Dragging it against the housing wall pushes dirt onto the clean side.
  • Check the seal face for dust tracks. A track means air was bypassing the element, not that the paper failed.
  • Reset the restriction indicator.

Replaced together

Change the oil filter in the same service stop. On SCR machines the two are usually scheduled together, and doing them at once avoids a second shutdown:

Genuine vs alternative

We supply the genuine SCR element. At this size the price gap to a copy is small and the labour to change it is identical, so there is little to gain by trading down.

Genuine SCR: USD 33

Ordering notes

Quote 25100130-072 with your machine model. Weight 1 kg, packed 18 × 18 × 50 cm. Ships in 5-7 days.
