47553061001 Ingersoll Rand Screw Air Compressor Genuine Parts Inlet Valve HAK85-10

No.47553061001
Ingersoll Rand HAK85-10 inlet valve 47553061001. 8 kg intake control valve for ML 55-75 screw compressors. In stock, USD 345.
$345.00
  • 47553061001 Ingersoll Rand Screw Air Compressor Genuine Parts Inlet Valve HAK85-10
  • 47553061001 Ingersoll Rand Screw Air Compressor Genuine Parts Inlet Valve HAK85-10
  • 47553061001 Ingersoll Rand Screw Air Compressor Genuine Parts Inlet Valve HAK85-10
  • 47553061001 Ingersoll Rand Screw Air Compressor Genuine Parts Inlet Valve HAK85-10
  • 47553061001 Ingersoll Rand Screw Air Compressor Genuine Parts Inlet Valve HAK85-10

Description

Part No 47553061001
Model HAK85-10
Brand Ingersoll Rand
Origin China
Weight 8 kg
Dimensions 37 × 30 × 25 cm
HS Code 8414909090
Fits Ingersoll Rand ML 55-75,MM55
Lead time In stock

What it does

The inlet valve is the throttle of the machine. It sits on the intake side of the airend and decides how much air enters, which is how the controller holds a pressure band instead of running flat out. On an ML machine the controller compares system pressure with the set point, works through the solenoid valve and the vent valve, and drives the servo cylinder that strokes this valve.

It also closes on shutdown, which is what allows the machine to start without load on the airend.

Signs it needs replacing

  • Pressure will not reach the set point, or takes far longer to get there
  • Rapid load and unload cycling with steady air demand
  • The valve stays partly open at shutdown, so the machine starts against pressure
  • Air escaping at the shaft seal, audible with the machine running unloaded
  • Oil mist at the intake after shutdown, a sign the valve is not seating

Replacement interval

Replace on condition. Seat and seal wear follow the number of cycles rather than running hours, so a machine on variable demand wears the valve faster than one running flat out. Inspect at 8,000 hours.

How to replace

  • Isolate and lock off, depressurise the sump, and vent the control air before opening anything.
  • Mark the control air ports. The valve moves the wrong way if two lines are crossed.
  • Check the servo cylinder and its diaphragm while the valve is off. A tired diaphragm mimics a worn valve.
  • Fit a new gasket and clean both faces. A reused gasket leaks past the seat and the symptom returns.
  • Cycle the machine through load and unload, then confirm the valve closes fully on stop.

Genuine vs alternative

Genuine Ingersoll Rand valve. The cheaper route for this part is a rebuild rather than a copy: the body outlasts the seat and seals several times over, so rebuilding keeps the original casting and the original port alignment.

Genuine Ingersoll Rand: USD 345

Ordering notes

Fits Ingersoll Rand ML 55-75. Send the machine model and serial with the part number so we can confirm the port arrangement before shipping.

Weight 8 kg, packed 37 × 30 × 25 cm. In stock.
