The diaphragm is the flexible element that separates the pilot air chamber from the process side of the valve. It flexes on every stroke, so it is also the part that eventually cracks or takes a permanent set.
Listed under part number 36622-00100. Match the diaphragm by part number and by outline; fabric-reinforced and plain diaphragms are not interchangeable.
