22150023-011P1/22150023-011P2 SCR Screw Air Compressor Genuine Parts Air Filter

No.22150023-011P1
Air intake filter element for SCR screw compressors, supplied as a two-part set: 22150023-011P1 together with 22150023-011P2. Both halves are needed for a complete element.
  • 22150023-011P1/22150023-011P2 SCR Screw Air Compressor Genuine Parts Air Filter
  • 22150023-011P1/22150023-011P2 SCR Screw Air Compressor Genuine Parts Air Filter
  • 22150023-011P1/22150023-011P2 SCR Screw Air Compressor Genuine Parts Air Filter
  • 22150023-011P1/22150023-011P2 SCR Screw Air Compressor Genuine Parts Air Filter
  • 22150023-011P1/22150023-011P2 SCR Screw Air Compressor Genuine Parts Air Filter

Description

Part information

Part No

22150023-011P1

Brand

SCR

Origin

China

HS Code

8414909090

Lead time

1-2weeks

What it does

This element is built in two sections that fit together inside the housing, which is why the part number carries a P1 and P2 suffix. Fitting only one half leaves an open face, and the machine draws unfiltered air through it without any obvious sign until the oil analysis shows dirt.

Signs it needs replacing

  • Dust on the inner face of the element after service, meaning one half was left out or not seated.
  • Restriction indicator in the red, or capacity down at full load.
  • Gap visible between the two sections when the element is assembled outside the housing.

Replacement interval

Clean at 1,000 hours, replace the complete set at 2,000-3,000 hours or when the restriction indicator stays red.

How to replace

  • Confirm both halves are present before the housing is closed; this is the most common mistake with a two-part element.
  • Seat the sections together first, then fit the assembly into the housing as one piece.
  • Check the outer seal all round before the cover goes back on.

Replaced together

The set is P1 plus P2 and both are supplied under this listing. Check the oil filter at the same service.

Genuine vs alternative

Genuine halves are matched as a set and the joint between them seals. Mixing a genuine half with a pattern half usually leaves a gap at the joint, and the machine pulls dust straight through it.

Ordering notes

Order the complete set; the P1 section alone will not seal the housing. Lead time is 1-2 weeks.
