1270485 Hoerbiger Air Compressor OEM Parts Inlet Valve HAK140-17.5

No.1270485
Hoerbiger inlet valve 1270485, model HAK140-17.5. Same valve as Ingersoll Rand 23421217. 17 kg unit for R132-160 compressors. USD 680.
$680.00
  • 1270485 Hoerbiger Air Compressor OEM Parts Inlet Valve HAK140-17.5
  • 1270485 Hoerbiger Air Compressor OEM Parts Inlet Valve HAK140-17.5
  • 1270485 Hoerbiger Air Compressor OEM Parts Inlet Valve HAK140-17.5
  • 1270485 Hoerbiger Air Compressor OEM Parts Inlet Valve HAK140-17.5
  • 1270485 Hoerbiger Air Compressor OEM Parts Inlet Valve HAK140-17.5

Description

Part No 1270485
Cross reference 23421217
Model HAK140-17.5
Brand Hoerbiger
Origin China
Weight 17 kg
Dimensions 53 × 40 × 30 cm
HS Code 8414909090
Fits Ingersoll Rand R132-160I / R132-160N
Lead time In stock

What it does

This is the HAK140-17.5 inlet valve on a large-frame screw compressor. It sits on the intake side of the airend and controls how much air the machine takes in, which is how the controller holds a pressure band rather than running the machine flat out. It closes on shutdown so the airend starts unloaded.

1270485 is the Hoerbiger number for this valve. At 17 kg and roughly 53 × 40 × 30 cm it is a substantial casting, and it is the seat rather than the body that wears.

Signs it needs replacing

  • Rated pressure is no longer reached, or takes much longer to build
  • The machine cycles load and unload rapidly against steady demand
  • It restarts loaded after shutdown, and the starter sounds strained
  • Air can be heard at the shaft seal with the machine unloaded
  • A polished band or step on the seat, visible once the valve is opened

Replacement interval

Replace on condition. The seat wears with every cycle, not with the clock, so hours on the meter are a poor guide on a machine with variable demand. Inspect at 8,000 hours.

How to replace

  • Isolate and lock off, vent the sump and the control air. Support the valve before undoing the flange — it is 17 kg and it will drop.
  • Record the control port layout before dismantling. On this size the lines are close together and easy to cross.
  • Fit a new gasket and clean the face. A distorted face over a seat this wide leaks in a way that mimics seat wear.
  • Inspect the servo cylinder for bore scoring while the valve is out.
  • Cycle load and unload, confirm closure on stop, then release the machine.

Which number do I need

Two numbers are in circulation for this valve: Hoerbiger 1270485 and Ingersoll Rand 23421217. They are the same HAK140-17.5 unit. A machine documented against a Hoerbiger service catalogue shows the first; an Ingersoll Rand parts book shows the second.

Both are stocked here as separate listings. Order by whichever number your manual shows. If you are not certain, send a photo of the old valve and we will confirm before you commit.

Ordering notes

Fits Ingersoll Rand R132-160I and R132-160N. Send the machine model and serial so we can confirm the variant before shipping.

Weight 17 kg, packed 53 × 40 × 30 cm. In stock.
